Study Recommends New Mezzanine to Connect Red/Purple at Silver Spring

July 10th, 2014 3 comments

To handle future ridership demand, Silver Spring may need a new mezzanine to connect Metrorail to the planned Purple Line light rail station.

Last year, we began a study looking at potential station capacity issues at Silver Spring.  The assessment determined that the demand at the Silver Spring Metrorail station (entries and exits) is adequately served by the existing station infrastructure.   Since then, the study has assessed the future conditions that will be impacted both by ridership growth due to growth of jobs and households in the station area, but also the arrival of the Purple Line light rail to Silver Spring.

Purple Line station and potential Metrorail connection at Silver Spring.  Source, purplelinemd.com, PDF.

Purple Line station and potential Metrorail connection at Silver Spring. Source, purplelinemd.com, PDF.

The Purple Line station at Silver Spring is planned as an elevated platform and mezzanine, with the mezzanine connecting to the top floor of Silver Spring Transit Center, Metropolitan Branch Trail, and  Ripley Street to the south.   The elevated light rail platform will be approximately 80 feet above the street, about the height of the current MARC pedestrian bridge.  The MTA design team envisioned a possible direct connection between Metrorail and the Purple Line, as illustrated in the red shape in the center of the above image.  Without such a connection, riders transferring between Metrorail and the Purple Line at Silver Spring would have to descend those 80 feet to the ground level, enter an existing Metrorail mezzanine, and then ascend again to the Red Line platform. Read more…

What’s the Ideal Size for a Transit Walkshed?

July 8th, 2014 2 comments

Large transit walksheds are great, but how big is big enough?

In other posts, we have described what a transit walkshed is, and how changes can be made to the pedestrian network to increase the walkshed area.  Here, we explore how big is big enough.

The diagram below shows a half-mile circle around a transit station.  If the station were located in a field of grass or on a massive parking lot, the walkable area of the circle would be the circle itself, 100% of the half-mile buffer around the station would be accessible by foot.  Unfortunately, that wouldn’t bode well for transit use, since there wouldn’t be any origins or destinations within that walking distance.

Ideal Walkshed DiagramNow, let’s lay a perfect grid of streets across that half-mile buffer.  The street area is where people can walk, and the remaining area contains houses, shops, mixed-use development, etc.  The resulting walkshed for the station begins to look like a diamond inscribed inside the circle.   The smaller the blocks (the closer the streets are to one another) the more the walkshed resembles a perfect diamond that has a diagonal distance equal to the diameter of the circle.  If you take the area of the diamond and that of the circle and compare them, you find the walkshed (square) covers 63.7% of the circular station area buffer.

So if you have a perfect grid and get 63.7% coverage, how can you get any better?  For one, diagonal streets can increase the coverage: if two diagonal streets were added to the grid, intersecting in the center of the circle at the transit station, the square walkshed would turn into an eight-pointed star, increasing coverage even more, but not by much.

An good example of a walkshed greater than 63.7% is that of the Takoma station.  Featured in a previous post, we recently calculated a 91% coverage for Takoma.

It is difficult to pick an ideal size for a transit walkshed.    A larger percentage could be beneficial, but the additional roadway network needed to expand the coverage beyond 63.7% may result in less area dedicated to potential transit origins and destinations.  (Remember the station in the parking lot?)

What Metrorail stations do you feel have good walkshed coverage?  In  your opinion, where can we improve?





New Blue Line Connections Revisited

July 3rd, 2014 22 comments

A recent Metro study determined that a Rosslyn bypass is infeasible but a second Metrorail station in Rosslyn to restore frequent peak period Blue Line service is possible.

In a post last year describing the strategies in Metro 2025, we described some options for new Blue Line connections.  The first was a Rosslyn bypass that would allow some Blue Line trains to connect directly to the Orange Line at Court House.  The second was a second Rosslyn station that would connect to the current Rosslyn station via an underground walkway.  Both of these options, illustrated in the graphics below, would allow increased frequencies on the Blue Line during peak periods.

Graphic for Rosslyn Interline ConnectionGraphic for Second Rosslyn Station

Metro recently completed a study that evaluated these two options.  The bad news is that the Rosslyn bypass (interline connection) was deemed infeasible.  This is due to the location of building foundations and the turning radius required by the track.

However, the second Rosslyn station was deemed feasible, as illustrated in the map below.

second_rosslyn

Location for a proposed second Rosslyn Station, including three potential options for a pedestrian walkway.

This new Metrorail station would connect to the current Rosslyn station via one underground walkway.

Metro Office of Planning is submitting the second Rosslyn station for project development funding.



How Can The Coverage of Transit Walk Sheds Be Increased?

July 1st, 2014 2 comments

Pedestrian infrastructure can cost-effectively increase coverage of transit walk sheds.

The roadway networks of most station areas are mostly unchangeable.  Existing structures on private property create unmovable barriers and  usually prevent new roads from being added to the network.  However, there is still opportunity to add pedestrian facilities that would increase a station’s walk shed in a relatively cost-effective way.

Take the example of Southern Ave Metrorail station.  We previously noted how a large number of customers drive to the station from between one and three miles away.  We discussed several reasons for this tendency to drive to Southern Ave, including the proximity to parks on both sides of the station.  The map below shows the transit walk shed of Southern Ave station.

Current walkshed of Southern Ave station.  The area with the orange dotted border contains over 1,200 households that could be within a half mile of Metrorail if a direct pedestrian connection were built.

Current walkshed of Southern Ave station. The area with the orange dotted border contains over 1,200 households that could be within a half mile of Metrorail if a direct pedestrian connection were built.



But what if a pedestrian path could be built to connect the station to the neighborhood to the north?

If a well lit, safe pedestrian path were constructed between the station and the orange-dotted area on the map, it could expand the walkshed to include up to 1,200 additional households in DC.  This new connection would likely increase ridership at Southern Ave. and might even generate enough additional fare revenue to fund the construction of the trail.

Metro’s Office of Planning is currently evaluating the walk sheds of our rail transit stations.  What other opportunities do you see for cost-effectively increasing the walk sheds around Metrorail stations?

BRT comes to DC via Hollywood

June 4th, 2014 1 comment
Video still showing Cleveland's center-running BRT, from the filming of Captain America, Winter Soldier.

Video still showing Cleveland’s center-running BRT, from the filming of Captain America, Winter Soldier.  Click image for original video.

I recently watched “Captain America:  The Winter Soldier” with some friends recently at the theater near Gallery Pl-Chinatown.  I had heard rumors that the film was set in DC, which was a selling point since it’s always fun hearing names of local streets or venues and picking out inconsistencies between Hollywood’s portrayal and the real thing.  Our friends over at Greater Greater Washington already noted that this film replaces parts of Rosslyn and Roosevelt Island with a massive S.H.I.E.L.D. headquarters complex.

But little did I know that the film would take me to Cleveland.  Read more…
